| GENERAL FEATURES | |
| Type | Online Single Phase (VFI) |
| Phases (IN-OUT) | 1-1 |
| Form Factor | Rack, Tower |
| Rack Units [U] | 5U |
| Power Capacity | 6000VA / 6000W |
| Output Power Factor | 1.00 |
| INPUT | |
| Input Voltage Range | 160-300V 100% load, 110-160V derating to 50% load linearly |
| Max THDi | <3% linear load; <5% non-linear load |
| Frequency Range | 40Hz – 70Hz |
| Frequency (Synchronized Range) | 50Hz or 60Hz |
| OUTPUT | |
| Waveform | Pure Sine Wave |
| Nominal Output Voltage | 220/230/240 VAC |
| Voltage Regulation (Battery Mode) | ±1% |
| INPUT & OUTPUT CONNECTORS | |
| Input Connector | Terminal |
| Output Type | Terminal |
| Terminal Output | Yes |
| TECHNICAL DETAILS | |
| LINE Mode Efficiency [%] (Full Load) | 95.0 |
| Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] | <10ms |
| Transfer Time (AC / Line Mode to Battery Mode) [ms] | 0ms |
| Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] | 10ms |
| Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] | 0ms |
| Additional Features | ECO Mode Available, CVCF Mode Available, OBM – Optimized Battery Management, Parallel Connectivity, REPO – Remote Emergent Power-Off, LCD Display, Unity Power Factor 1.0, Battery Pack Available, IoT – Cloud Connectivity, Generator Compatible, HID – Human Interface Device, Hot-Swappable Batteries, EBM – External Battery Module – Auto Detection |
| IEC 62040-3 classification | VFI-SS-111 |
| BATTERIES AND AUTONOMY | |
| Batteries | 20x 12.0V/7.0Ah |
| DC Voltage | 20x 12.0V |
| Recharge Time | 3h to 90% |
| Full Load Backup Time [min] | 7.2 |
| Half Load Backup Time [min] | 17.7 |
| Charger | 1A – 4A [1.4A] |
| External Battery Pack | Yes |
| COMMUNICATION | |
| Communication | Dry contact, USB Type B – for Monitoring Software, RS-232, WLAN Port – for Internet Connection, Management Card Slot, RJ-45 – for Internet Connection |
| Software | WinPower |
| Parallel Operation [Units] | 3 |
| ENVIRONMENT | |
| Noise Level | < 55db |
| Fan Logic | Always on, Automatic Speed Control |
| Temperature | 0°C – 45°C |
| Humidity | 0% – 95% RH (non-condensing) |
| IP | IP 20 |
| LOGISTICS | |
| Package Content | Bundle (Please see additional packaging information) |
| Manual Languages | EN |
| EAN | 4260074983197 |
| Product Dimensions (DxWxH) [mm] | 559 x 438 x 215 mm |
| Product Weight [kg] | 69.4 |
| Addtional Packaging Information | This is a Bundle Product.For theindividual packaging information please look at the following Article Number:10122202(UPS Engine) +10124056(EBM). |
| Pcs. per Outer Carton | 1 |
| Attribute name | Attribute value |
|---|---|
| UPS Type | On-line |
| Output Connections | Terminal |
| UPS Power Capacity | 6000W |
| Form Factor | Tower/Rackmount |
| UPS Features | Pure Sine Wave |
