| GENERAL FEATURES | |
| Type | Online Single Phase (VFI) |
| Phases (IN-OUT) | 1-1 |
| Form Factor | Tower |
| Power Capacity | 6000VA / 6000W |
| Output Power Factor | 1.00 |
| INPUT | |
| Input Voltage Range | 110-300 VAC @ 0-60% load 140-300 VAC @ 60-80% load 176-300 VAC @ 80-100% load |
| Max THDi | ≤4% @ 100% load; ≤6% @ 50% load |
| Frequency Range | 50Hz or 60Hz (self-adaptive) |
| Frequency (Synchronized Range) | 46Hz – 54Hz or 56Hz – 64Hz |
| OUTPUT | |
| Waveform | Pure Sine Wave |
| Nominal Output Voltage | 208/220/230/240 VAC |
| THDv | ≤1% @ 100% linear load, ≤4% @ 100% non-linear load |
| Voltage Regulation (Battery Mode) | ±1% |
| Frequency (Battery Mode) | ±0.1Hz |
| INPUT & OUTPUT CONNECTORS | |
| Input Connector | Terminal |
| Output Type | Terminal |
| Terminal Output | Yes |
| TECHNICAL DETAILS | |
| LINE Mode Efficiency [%] (Full Load) | 94.0 |
| Battery Mode Efficiency [%] (Full Load) | 91.0 |
| Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] | <10ms |
| Transfer Time (AC / Line Mode to Battery Mode) [ms] | 0ms |
| Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] | <10ms |
| Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] | 0ms |
| Load Crest Ratio | 3:1 |
| Bypass | Manual – Bypass |
| Additional Features | Earthing System Available, Parallel Connectivity, LCD Display, Unity Power Factor 1.0, Input Breaker, Battery Pack Available, Generator Compatible, EPO – Emergency Power Off, HID – Human Interface Device, AVR – Automatic Voltage Regulator |
| IEC 62040-3 classification | VFI-SS-111 |
| BATTERIES AND AUTONOMY | |
| Batteries | 20x 12.0V/9.0Ah |
| DC Voltage | 20x 12.0V |
| Recharge Time | 9h to 90% |
| Full Load Backup Time [min] | 6.5 |
| Half Load Backup Time [min] | 17.0 |
| Charger | 1A, 2A, 4A |
| External Battery Pack | Yes |
| COMMUNICATION | |
| Communication | USB Type B – for Monitoring Software, RS-232, Management Card Slot |
| Software | ViewPower |
| Parallel Operation [Units] | 2 |
| ENVIRONMENT | |
| Noise Level | < 58dB |
| Fan Logic | Always on, Automatic Speed Control |
| Temperature | 0°C – 40°C |
| Humidity | 20% – 95% RH (non-condensing) |
| IP | IP 20 |
| LOGISTICS | |
| Package Content | Manual, USB Cable, UPS |
| Manual Languages | DE, EN |
| EAN | 4260074978650 |
| Product Dimensions (DxWxH) [mm] | 369 x 190 x 688 mm |
| Product Weight [kg] | 57.0 |
| Package Dimensions (DxWxH) [mm] | 570 x 310 x 785 mm |
| Package Weight [kg] | 77.8 |
| Pcs. per Outer Carton | 1 |
| Attribute name | Attribute value |
|---|---|
| UPS Type | On-line |
| Output Connections | Terminal |
| Form Factor | Tower |
| UPS Power Capacity | 6000W |
| UPS Features | Pure Sine Wave |
