Case Specification
Dimensions 420 x 210 x 402mm (LxWxH)
Form Factor Micro-ATX
Materials SPCC & Plastic
Mainboard Support Micro-ATX、Mini-ITX
Front Access & Controls USB3.0 x 2, MIC/AUDIO(HD), Power, Reset, Mode
Side Panel Tempered Glass Side Panel
Expansion & Drive Bays
Expansion Slots 4
5.25" 0
3.5"/2.5" (convertible) 2
2.5" 2
Cooling
Front 3 x 120mm / 2 x 140mm
Top 2 x 120mm / 2 x 140mm
Rear 1 x 120mm
Included Fan(s) 1 x 120mm in rear
Radiator Support
Front ≤ 280mm
Rear ≤ 120mm
Clearance
Max GPU Length ≤ 360mm
Max CPU Height ≤ 160mm
Max PSU Length ≤ 170mm
Others
Dust Filters Top / Bottom
UPC# 0-761345-80020-4
Package Dimension 455 x 260 x 485 mm (DWH)
Products specifications
Attribute name | Attribute value |
---|
Side Panel | Glass |
Case Colour | Black |
Case Form Factor | Mini-Tower |
Motherboard Form Factor | mATX, ITX |
PSU Form Factor | ATX |
Consumption | 15w |
