POWER
AC adapter input 100-240V ~ 50/60Hz 0.8A
AC adapter output 12V ⎓ 2A
HARDWARE FEATURES
Ports 2 * LAN/WAN Gigabit Ethernet Ports
1 * USB 2.0 Port (reserved)
1 * Power Port
Button 1 Reset button on the underside
External Power Supply 12 V/2 A
Dimensions Φ5.7 in. x 2.5 in. (Φ144 mm × 64 mm)
Antenna Type 6 WiFi, 1 ZigBee & 1 Bluetooth
WIRELESS FEATURES
Wireless Standards IEEE 802.11 ac/n/a 5 GHz
IEEE 802.11 b/g/n 2.4 GHz
Bluetooth 4.2
ZigBee HA1.2
Frequency 2.4 GHz and 5 GHz
Signal Rate 867 Mbps at 5 GHz (1)
867 Mbps at 5 GHz (2)
400 Mbps at 2.4 GHz
Transmit Power FCC: <30 dBm
Wireless Security WPA-PSK/WPA2-PSK
Advanced Functions ● Router/ Access Point Mode
● Optional Ethernet Backhaul
● TP-Link Mesh Technology:
MU-MIMO
Auto Path Selection
Self-Healing
AP Steering
Band Steering
Beamforming
SOFTWARE FEATURES
Quality of Service WMM
WAN Type Dynamic IP/Static IP/PPPoE
Management Local Management, Remote Management
DHCP Server, Client
Firewall Security SPI Firewall
Protocols Supports IPv4 and IPv6
Advanced Features Parental Controls
3-Year Free Built-In Antivirus
QoS (Quality of Service)
Reporting
Assisted Setup
Works with Alexa & IFTTT
Automation (for smart home devices)
Guest Network 2.4 GHz guest network * 1
5 GHz guest network * 1
OTHERS
Package Contents ●Deco M9 Plus (3-pack):
3 Deco units
1 RJ45 Ethernet Cable
3 Power Adapters

●Deco M9 Plus (2-pack):
2 Deco units
1 RJ45 Ethernet Cable
2 Power Adapters

●Deco M9 Plus (1-pack):
1 Deco unit
1 RJ45 Ethernet Cable
1 Power Adapter
Smartphone/Tablet Requirements iOS 9.0 or later
Android 4.4 or later
Bluetooth 4.0 or later
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
