P/N
CA-1X2-00M1WN-00
SERIES
S Series
CASE TYPE
Mid Tower
DIMENSION (H X W X D)
460x 210 x 395.3 mm
(18.11 x 8.27 x 15.56 inch)
NET WEIGHT
4.8 kg / 10.6 lbs.
SIDE PANEL
3mm Tempered Glass x 1
COLOR
Black
MATERIAL
SPCC
COOLING SYSTEM
Front(intake):
120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 3
DRIVE BAYS
2 x 3.5”, 2 x 2.5” or 1 x 3.5”, 3 x 2.5”
EXPANSION SLOTS
7
MOTHERBOARDS
6.7" x 6.7" (Mini ITX), 9.6" x 9.6" (Micro ATX),
12" x 9.6" (ATX)
I/O PORT
USB 3.0 x 2, HD Audio x 1
PSU
Standard PS2 PSU (optional)
FAN SUPPORT
Front:
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Top:
2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Rear:
1 x 120mm
RADIATOR SUPPORT
Front:
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Top:
1 x 240mm, 1 x 120mm
Rear:
1 x 120mm
CLEARANCE
CPU cooler max height:
166mm
VGA max length:
300mm (with radiator)
330mm (without radiator)
PSU max length:
190mm (with HDD Cage)
