P/N CL-F115-PL12SW-A
FAN DIMENSION 120 x 120 x 25 mm
INTERFACE Fan 2510-4P , LED 5V RGB Header
STARTED VOLTAGE 9.0 V
RATED CURRENT Fan 0.17 A , LED 0.28 A (Fan*1)
RATED VOLTAGE 12 V & 5V
POWER INPUT 12V – 4.08 W , 5V – 2.8 W (Fan*2)
FAN SPEED PWM 500~1500 R.P.M
MAX. AIR PRESSURE 1.72 mm-H2O
MAX AIR FLOW 56.51 CFM
NOISE LEVEL 28 dB-A
BEARING TYPE Hydraulic Bearing
LIFE EXPECTATION 40,000 hrs, 25℃
WEIGHT 168 g (Fan*1)
