General features
Type Line-Interactive
Power capacity 600VA / 360W
Output Power Factor 0.60
Input
Input Voltage Range 162-290 VAC
Frequency Range 50Hz or 60Hz (self-adaptive)
Frequency (Synchronized Range) 50Hz or 60Hz
Output
Nominal Output Voltage 230 VAC
Voltage Regulation (Bat. Mod.) ±10%
Frequency (Battery Mode) ±1Hz
Technical details
Transfer Time [AC to Battery] 2-6ms
Overload Capacity N/A
Charger 1A
Protection Overload, discharge and overcharge protection
Fan Logic No fan
Efficiency
LINE mode full Load 94.0%
Batteries and autonomy time
Batteries 1x 12V/7Ah
DC Voltage 1 x 12V
Recharge Time 4h to 90%
Full Load Backup Time 0.1min
Half Load Backup Time 6min
Connections and communication
BS-1363 (Type G) UK Outlet 2
Input UK
Software ViewPower
USB port Yes
HID Support Yes
RJ-45/RJ-11 protection Yes
Environment
Noise Level < 40dB
Temperature 0°C – 40°C
Humidity 0% - 90% RH (non-condensing)
Logistics
Package Content UPS, Manual
Manual Languages EN/DE/FR/IT/ES/PT/PL/RU
EAN 4260074982251
Width 101 mm
Height 142 mm
Depth 300 mm
Weight 4.4 kg
Giftbox - Width 140 mm
Giftbox - Height 220 mm
Giftbox - Depth 344 mm
