The PowerWalker VI R1U is a line interactive 1U rack UPS solution. Thanks to its 1U design, the UPS fits in nearly every setting. It is equipped with pure sine wave output and an optional card slot for network cards, so that even sensitive and critical loads can be kept safe. The PowerWalker VI R1U is a flexible all-rounder for home and semi-professional environments.
Manufacturer: Powerwalker
SKU: PUP0150
Availability: Out of stock
€538.08 excl tax


General features
Type Line-Interactive
Power capacity 1000VA / 600W
Output Power Factor 0.60
Input
Input Voltage Range 165-290 VAC
Frequency (Synchronized Range) 50Hz or 60Hz
Output
Nominal Output Voltage 230 VAC
Pure Sine Wave Yes
THDv ≤3% Full Linear Load; ≤5% Non-Linear Load
Voltage Regulation (Bat. Mod.) ±10%
Frequency (Battery Mode) ±0,5Hz
Technical details
Transfer Time [AC to Battery] 4ms typical
Charger 1A
Protection Overload protection on utility: fuse; on battery: internal current limiting
Efficiency
LINE mode full Load 95.0%
Energy Star compliance
Batteries and autonomy time
Batteries 4x 6V/7Ah
DC Voltage 4 x 6V
Recharge Time 8h to 90%
Full Load Backup Time 0.8min
Half Load Backup Time 10.3min
Connections and communication
IEC C13 Outlet 4
Input C14
Software PowerMaster
USB port Yes
HID Support Yes
RS-232 Port Yes
Extension Slot Yes, 1
EPO Port Yes
Environment
Noise Level No Fan
Temperature 0°C – 40°C
Humidity 0% - 90% RH (non-condensing)
Logistics
Package Content UPS, Manual, USB Cable, Input Power Cable, Rack Ears
Manual Languages EN
EAN 4260074980400
Width 433 mm
Height 44 mm
Depth 485 mm
Weight 14.2 kg
Giftbox - Width 553 mm
Giftbox - Height 150 mm
Giftbox - Depth 475 mm
Giftbox - Weight 16.5 kg

Products specifications
Attribute nameAttribute value
UPS FeaturesRackmount, LCD, Pure Sinewave
UPS TypeOnline
Output ConnectionsC13
UPS PowerUp to 1000 VA
