Pure Sine Wave Output for a Wide Range of Applications and Harsh Environments Maximal PV peak power 1200W with PWM charger type technology Output Power Factor 1.0 Strong Configurable AC/ PV (Solar) Charger Smart Battery Charger Design for Optimized Battery Performance Generator compatible The PowerWalker Inverter PWM series is a multi-functional Inverter/ Charger, combining functions of inverter, solar charger and battery charger to offer uninterruptable power support with portable size. Its comprehensive LCD offers user-configurable and easy-accessible button operation such as battery charging current, AC/ PV (solar) charger priority, and acceptable input voltage based on different applications.

Manufacturer: Powerwalker

SKU: PIN0005

Manufacturer part number: 10120224

GTIN: 4260074982992

Availability: Out of stock

€394.02 excl tax

Qty:

Full Description

General Features
Type	Inverter
Phases (IN-OUT)	1-1
Form Factor	Wall-Mountable
Power Capacity	3000VA / 3000W
Output Power Factor	1
Input
Input Voltage Range	170-280 VAC (narrow range) 90-280 VAC (wide range)
Frequency Range	50Hz or 60Hz (self-adaptive)
DC Input (PV)
Maximum PV Power [W]	1200
Maximum PV Voltage [V]	80
Output
Waveform	Pure Sine Wave
VA	3000
Nominal Output Voltage	230 VAC
Output Power Factor	1
Input & Output Connectors
Input Connector	Terminal
Terminal Output	Yes
Technical Details
LINE Mode Efficiency [%] (Full Load)	96.6
Battery Mode Efficiency [%] (Full Load)	88.2
Transfer Time (AC / Line Mode to Battery Mode) [ms]	10ms Normal Range (20ms Wide Range)
Additional Features	Wall Mountable, Earthing System Available, PV (Photovoltaic) Charging Supported, LCD Display, Unity Power Factor 1.0, Circuit Breaker Reset, Generator Compatible, External Battery Compatible
Batteries and Autonomy
Batteries	Batteries not Included
DC Voltage	2x 12.0V
Charger	AC/ PV (Solar) Charger (Type: PWM)
External Battery Pack	Terminal
Compatible Battery Type	Lead-Acid Batteries,Lithium Batteries
Maximum PV / AC Charge Current [A]	Max. Solar Charger Current: 50A Max. AC Charger Current: 15-25A Max. combined Charger Current: 70A
Communication
Communication	USB Type B – for Monitoring Software
Software	WatchPower
Management and Environment
Software	WatchPower
Communication	USB Type B – for Monitoring Software
Noise Level	< 55db
Fan Logic	Always on, Automatic Speed Control (Mode and Temperature Dependent)
Temperature	-10°C – 50°C
Humidity	5% – 95% RH (non-condensing)
IP	IP 20
Logistics
Package Height [mm]	216
Package Width [mm]	400
Package Depth [mm]	500
Package Weight [kg]	8.6
Product Height [mm]	334
Product Width [mm]	285
Product Depth [mm]	100
Product Weight [kg]	6.3
Package Content	USB Cable, Manual, CD, Inverter
EAN	4260074982992
Product Dimensions (DxWxH) [mm]	100 x 285 x 334 mm
Package Dimensions (DxWxH) [mm]	500 x 400 x 216 mm
Pcs. per Outer Carton	1
