Total Cores 6
Total Threads 12
Max Turbo Frequency 4.40 GHz
Intel® Turbo Boost Technology 2.0 Frequency‡ 4.40 GHz
Processor Base Frequency 2.60 GHz
Cache 12 MB Intel® Smart Cache
Bus Speed 8 GT/s
TDP 65 W

Memory Specifications
Max Memory Size (dependent on memory type) 128 GB

Memory Types
DDR4-3200
Max # of Memory Channels 2
Max Memory Bandwidth 50 GB/s
ECC Memory Supported ‡No
Processor Graphics
Processor Graphics ‡ Intel® UHD Graphics 730

Graphics Base Frequency 350 MHz

Graphics Max Dynamic Frequency 1.30 GHz
Graphics Video Max Memory 64 GB

Execution Units 24
4K Support Yes, at 60Hz
Max Resolution (HDMI)‡ 4096x2160@60Hz
Max Resolution (DP)‡ 5120 x 3200 @60Hz
Max Resolution (eDP - Integrated Flat Panel)‡
5120 x 3200 @60Hz
DirectX* Support 12.1
OpenGL* Support 4.5
OpenCL* Support 3.0
Intel® Quick Sync Video Yes
Intel® InTru™ 3D Technology Yes
Intel® Clear Video HD Technology Yes
Intel® Clear Video Technology Yes
# of Displays Supported  3

Device ID 0x4C8B
Expansion Options
Scalability 1S Only
PCI Express Revision 4.0
PCI Express Configurations ‡ Up to 1x16+1x4, 2x8+1x4, 1x8+3x4
Max # of PCI Express Lanes 20
Package Specifications
Sockets Supported FCLGA1200
Max CPU Configuration 1
Thermal Solution Specification PCG 2019C
TJUNCTION 100°C

Package Size 37.5 mm x 37.5 mm

Advanced Technologies
Intel® Gaussian & Neural Accelerator 2.0
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Optane™ Memory Supported ‡ Yes
Intel® Thermal Velocity Boost No
Intel® Turbo Boost Max Technology 3.0 ‡ No
Intel® Turbo Boost Technology ‡ 2.0
Intel® Hyper-Threading Technology ‡ Yes
Intel® 64 ‡ Yes
Instruction Set 64-bit

Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2, Intel® AVX-512
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Intel® Identity Protection Technology ‡ Yes
Security & Reliability Intel® AES New Instructions Yes
Secure Key Yes
Intel® Software Guard Extensions (Intel® SGX) No
Intel® OS Guard Yes
Intel® Trusted Execution Technology ‡ No
Execute Disable Bit ‡ Yes
Intel® Boot Guard Yes
Intel® Stable IT Platform Program (SIPP) No
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
