Interface PCI-Express 3.0 x4, NVMe 1.3
Form Factor M.2 2280
Total Capacity 256GB
NAND NAND Flash
External DDR Cache N/A
Sequential Read speed Up to 1700 MB/s
Sequential Write speed Up to 1100 MB/s
Random Read IOPS Up to 180k
Random Write IOPS Up to 250k
Dimension 80 x 22 x 2.3 mm
Mean time between failure (MTBF) 1.5M hours
Power Consumption (Active)Avg. read : 2.6W ; Write : 2.4W
Power Consumption (Idle) 1.9mw
Temperature (Operating) 0°C to 70°C
Temperature (Storage) -40°C to 85°C
