Interface PCI-Express 4.0x4, NVMe 1.3
Form Factor M.2 2280
Total Capacity 500GB
NAND 3D TLC Toshiba BiCS4
External DDR Cache DDR4 512MB
Sequential Read speed Up to 5000 MB/s
Sequential Write speed Up to 2500 MB/s
Random Read IOPS up to 400k
Random Write IOPS up to 550k
Dimension 80.5 x 11.25 x 23.5 mm
Mean time between failure (MTBF)
1.77 million hours
Power Consumption (Active)
Average: R : 5.9W; W : 4.5W
Power Consumption (Idle)
13.21mW
Temperature (Operating)
0°C to 70°C
Temperature (Storage)
-40°C to 85°C
