General Specifications
Platform
Desktop
Product Family
AMD Ryzen™ Processors
Product Line
AMD Ryzen™ 9 Desktop Processors
# of CPU Cores
16
# of Threads
32
Max. Boost Clock
Up to 5.7GHz
Base Clock
4.5GHz
L1 Cache
1MB
L2 Cache
16MB
L3 Cache
64MB
Default TDP
170W
Processor Technology for CPU Cores
TSMC 5nm FinFET
Unlocked for Overclocking
Yes
CPU Socket
AM5
Thermal Solution (PIB)
Not included
Max. Operating Temperature (Tjmax)
95°C
Launch Date
9/27/2022
*OS Support
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
System Memory Type
DDR5
Memory Channels
2
Max Memory Speed
2x1R
DDR5-5200

2x2R
DDR5-5200

4x1R
DDR5-3600

4x2R
DDR5-3600

Graphics Capabilities
Graphics Model
AMD Radeon™ Graphics
Graphics Core Count
2
Graphics Frequency
2200 MHz
GPU Base
400 MHz
Product IDs
Product ID Boxed
100-100000514WOF
Product ID Tray
100-000000514
Key Features
Supported Technologies
AMD EXPO™ Technology
AMD Ryzen™ Technologies
